Coil D with 1200 Turns - 1000989
Coils, covered with impact resistant plastic so that they are safe to touch, for use as primary or secondary coils in combination with the transformer core D (1022664). With safety connection sockets.
As secondary coils these can output either low or high voltage, depending on the primary voltage, and therefore they cannot be used in student experiments.
Specifications:
-
Number of turns: 1200
-
Taps: 400/1200
-
Resistance: 12 Ω
-
Max. current: 1.2 A
-
Inductance: 60 mH
4.7 x 3.5 x 2.8 in
